Quick Details
|
||
|
Gearing Arrangement: Planetary
|
Output Torque: ?7251.81 N.m
|
Rated Power: 0.25-7.5 kw
|
| Model Number: SBD | Brand Name: XINGHAIWANG | certification: ISO9001:2008 |
By Industry
Packaging & Delivery
Packaging Details: standard export packing ,inner packing is opp bag, outside packing is wooden case, or According to the
customer's requirements packaging.
Delivery Detail: 20 days after confirmation
Specifications
1,little vibration, low noise, energy-saving high;
2,short delivery term
3,flange and foot mounting
4,with all kinds of motor
Specifications
1,Type: SBD50,SBD50A,SBD65,SBD75,SBD85
2,Min: 1set
Reducer models and some technical show
| Types | Motor power | Transmission ratio | Installation | Velocimetry way | Output shaft aperture diameter |
| 50 | 0.25-1.1KW | 48.375-1922.570 | P,G | A,B | 28 35 40 |
| 50A | 0.25-1.1KW | 48.375-2101.265 | J,P,G | A,B | 28 35 40 |
| 65 | 0.25-3KW | 36-2313.6 | W,P,G | A,B | 40 45 50 |
| 75 | 0.55-4KW | 34-1883.55 | J,P,G | A,B | 50 55 60 |
| 85 | 0.75-7.5KW | 32-1888.24 | J | A,B | 60 65 70 |
INSTALLATION MODELS
| BASIC | FOOT PLATE | HANDING | FALNGE |
| J | W | P | G |
